Performance Parameter
|
|
|
Operating system
|
Microsoft Windows CE 6.0 / Android 6.0
|
|
Processor
|
1GHz / Eight-core 1.3GHz
|
|
Memory
|
512MB RAM+512MB ROM / 2G RAM+16G ROM
|
|
Physical Parameter
|
|
|
Display screen
|
3.5" 480x640TFT color touch screen
/ 3.5" 480*640 capacitance touch HD screen
|
|
Camera(optional)
|
5 mega pixel, autofocus, LED light
/ 13 mega pixel, autofocus, LED light
|
|
Input method
|
English, Arabic input method, pinyin and handwriting input
/ English input, installation of input method supported
|
|
Working time
|
Above 10 hours in regular use Above 280 hours standby
/ Above 8 hours in regular use Above 200 hours standby
|
|
Battery
|
UnLoadable 3.8V 3200mAH lithium battery
|
|
Dimen sions
|
L210 mm x W79 mm xT28 mm
|
|
Weight
|
360g(standard battery included)
|
|
Keyboard
|
52 regular keys, 1 power switch key, 1 reset key, 2 side keys
|
|
Power adapter
|
Input: AC 100 - 220V 50/60HZ: Output: DC 2.5A
|
|
Audio(optional)
|
3.5mm stereo headphone jack,built-in speaker and built-in
microphone(optional)
|
|
Notification
|
Loudspeaker, indicator light and vibration
|
|
Interfacel（optional）
|
Industry grade Micro USB 2.0 data interface, Micro SD/TF card
sbt,
SIM card slot (optional), Charging interface, PSAM slot
|
|
Environmental Parameter/IP Rate
|
|
|
Temperature
|
Working ：-10°C - 50°C Storage：-30°C - 60°C
|
|
Electrostatic
|
±15kV air discharge, ±8kV direct discharge
|
|
Relative humidity
|
5% ~ 95%RH
|
|
Protection grade
|
IP65 grade
|
|
Height of anti-dropping
|
2.5m(0n concrete ground)
|
|
Strength of anti-rolling
|
1m(More than 1000 rolling by impact force)
|
|
Communication Data Parameter
|
|
|
WiFi
|
IEEE 802.11 a/b/g/n / IEEE 802.11 a/b/g/n
|
|
Bluetooth
|
Bluetooth 2.1
/ Bluetooth 4.0
|
|
WWAN (optional）
|
GPRS/WCDMA/EVDO
/ GPRS/WCDMA/EVDO/TDSCDMA/TDD-LTE/FDD-LTE
|
|
GPS (optional）
|
Precision：10m(open skylloptionaL for Android OS)
|
|
Identification Parameter
|
|
|
Barcode(optional)
|
1D Laser/2D image scanning engine
Scanning precision: ^ 3 mil
Reading distance: 3cm-70cm(Depends on barcode density and code system]
UPC/EAN, Code128, Code39, Code93, Codell, Interleaved 2 of 5, Discrete 2 of
5,
Chinese 2 of 5, Codabar, MSI, RSS etc；PDF417, MicroPDF417, Composite,
RSS, TLC-39,Data matrix, QR code, Micro QR code,Aztec,Postal Codes： US PostNet；
US Planet,UK Postal； Japan Postal Dutch
Postal (KlX)etc.
|
|
Certificates
|
|
|
CCC，Rohs，IP65grade, CE, FCC and IS09001
|
