| Display |
| Size |
10.1 inch (16:10) |
| Touch Type |
VT-768K: 5-wire resistive touch, VT-768KC: Projected capacitive multi touch |
| Display Type |
TFT LCD |
| Resolution |
1280 x 800 |
| Luminance |
400 nits |
| Contrast Ratio |
900: 1 |
| View Angles |
85 (left), 85 (right), 85 (up), 85 (down) |
| Color |
16.7M |
| System |
| CPU |
Intel® Celeron® J1900 processor (quad core, 2.0 GHz) |
| Chipset |
Intel® Atom® and Celeron® Processor SoC |
| Memory |
4GB DDR3L-1333 SO-DIMM (up to 8GB) |
| Storage |
128GB mSATA SSD (up to 512GB) |
| Graphics |
Intel® HD Graphics |
| BIOS |
SPI BIOS |
| Keypad & Keyboard |
| Keypad |
Power on/off
Brightness adjustment
F1-F6 user-defined function keys
Power LED indicator |
| I/O Ports |
| USB |
1x USB 2.0 (Type A)
1x USB 3.0 (Type A) |
| Serial |
1x RS-232/422/485 (COM1 supports 5V/12V, DB9)
1x RS-232 (COM2 supports 5V, DB9) |
| Ethernet |
1x GbE LAN |
| SIM Card Slot |
1x Nano SIM socket |
| DIO |
4x DI + 2x DO (optional, with 3.3V, replace COM2 port) |
| CAN bus |
2x CAN2.0B (optional, supports J1939 protocol, compatible-layout with COM2 port) |
| Antenna |
2-4x TNC connector for external antenna (Wi-Fi, Bluetooth, WWAN, GPS) |
| RF Communication |
| Wi-Fi |
Wi-Fi 5: 802.11a/b/g/n/ac, 2.4G/5G (optional)
Wi-Fi 6E: 802.11a/b/g/n/ac/ax, 2.4G/5G (optional) |
| Cellular |
4G, LTE (optional)
5G, NSA/SA (optional) |
| Bluetooth |
Bluetooth 4.0/5.3 (optional) |
| GNSS |
GPS, GLONASS, Galileo, BeiDou (optional, Ublo x NEO M8N) |
| Audio |
| Speaker |
8Ω/2W, mono speaker |
| Power |
| DC Input |
8 to 36VDC |
| Power Consumption |
15W (Typ.) |
| Ignition On/Off |
Power on delay, default 10 seconds
Power off delay, default 10 seconds
(on/off delay time can be changed via BIOS setting) |
| Battery |
7.2V 3350mAh (optional) |
| Power Mode |
ATX (default), AT |
| Operating System |
| Windows |
Windows 10 IoT Enterprise LTSC
Windows 10 Pro |
| Mechanical |
| Dimensions (W x D x H) |
280 x 210 x 46 mm (11.02 x 8.27 x 1.81 inches) |
| Weight (N.W.) |
2.2 kg (4.85 lbs) |
| Mounting Mode |
VESA 75 and 100 |
| Material |
Die-casting aluminum with heavy duty metal |
| Environment |
| Operating Temperature |
-20 to 60℃ (-4 to 140°F) |
| Storage Temperature |
-40 to 70℃ (-40 to 158°F) |
| Relative Humidity |
95% @ 70°C (158°F), non-condensing |
| Shock |
MIL-STD-810G Method 516.6 Procedure I |
| Vibration |
MIL-STD-810G Method 514.6 Procedure I |
| IP Rating |
IP65 compliant (I/O interface must be closed) |
| Certification |
| EMC |
CE, FCC |
