Product Form | Type | Rugged Tablet |
Dimension | 305*205*16.5 mm |
Weight | Device unit: 630g ，Unit with giftbox and standard accessories:1330g，docking：290g |
Device Color | black+ silver ( bottom shell in silver color, front shell in black) |
LCD | Screen Size | 11.6“ 16:9 |
Resolution | 1920(H)×1080(V) |
Brightness | 350Nit |
TP | Touch Panel | Multipoints Capacitive，G+G，Corelle gorilla, hardness over 7H, scratch resistant，TP thickness：1.1mm，COF，support windows ink |
Camera | Front | Front:2.0MP |
Rear | Rear: 5.0MP |
Speaker | build in | Embedded 8Ω/0.8W waterproof speakerx 1 |
Mic | build in | Sensitivity:-42db, output resistance2.2kΩ |
Battery | Type | Lithium-ion polymer battery ，pluggable, dimension: 21.8*92.3*9.5mm |
Capacity | 5000mHA/7.4V |
Endurance | 6 hours (default 50% volume, default 200 lumens brightness, play 1080p HD video) |
GPU | Type | Intel®skylake Core™ m3-7Y30 |
Speed | 2.6GHz |
GPU | Type | Intel® HD Graphics |
RAM | DDR3L | 8G |
ROM | Emmc | 128G |
G-sensor | build in | G sensor |
WIFI | WIFI module | WIFI 802.11(a/b/g/n/ac) frequency 2.4G+5.8G double frequency WIFI |
Bluetooth | build in | BT4.0 (BLE) class1 transmission distance：10m |
3G | build in | FIBOCOM_H380-GL frequency range：GSM/GPRS/EDGE Band(850&900&1800&1900 MHZ), WCDMA |
GPS | build in | U-blox NEO-7,support :GLONASS,QZSS,GPS;acquisition sensitivity:-160 dBm；Cold start time ： |
2D | OPTIONAL | NA |
2D | OPTIONA | NA |
TF slot | Extensive External Memory | support SDHC/SDXC x1 max：64G host |
USB Interface | Extend external memory and data | USB 2.0*2 vs USB3.0*1 |
Earphone Jack | transfer Audio Output | ∮3.5mm standard earphone jack x1 |
DC Jack | Power | DC 12V 4A power interface x1 host |
HDMI | Video Output | HDMI 1.4a Type C x1 |
Power Adaptor | Standard | AC100V ~ 240V、50Hz/60Hz outputting DC 12V/4A CE certification |
Operation System | OS version | Windows 10 64bit English |
Certificate System | IP65 | IP65 report: Waterproof test: IP-x5, dustproof test: IP-6X a.ozzle bore: 6.3mm; B. water flow: 12.5 + 0.625L/min; c.Water pressure: according to the regulation of water flow regulation; d. the main part of the main flow: a circle about 40mm in diameter from the nozzle 2.5m; e.Shell surface water per square metre: About 1min; F. test time: at least 3min; g.Nozzle to shell surface distance: 2.5 ~ 3m. After test, the sample is not flooded |
MIL-STD-810G | Y |
Product Reliability | Drop Height | 1.0 M composite wooden floor boot status |
Operate Temperature | -20 °C to 60 °C -4 °F to 140 °F |
Store Temperature | -30 °C to 70 °C / -22 °F to 158 °F |
Humidity | Humidity: 95% Non-Condensing |
